Products

Heavy forgings are made by open die forging (free drop forgings), such as: shafts, blocks, flanges, tubes, gears. These forging parts are used for Vessels, Plastic Extrusion Machines, Gearbox and so on.

Closed die fogings include spares for Construction Equipments, Mining, & Agriculature Machineries and shipbuildings.

Pallet Fork-01

TYPE FORKS（1T-10)
TYPE HOOK	item	length mm	widtth mm	thickness mm	material	weight kg/piece
CLASS IIA	1t fork	770	100	31	40Cr	32
		850	100	31	40Cr	33
		920	100	31	40Cr	35
	1.5t fork	920	100	35	40Cr	37
		1000	100	35	40Cr	38
		1070	100	35	40Cr	40
		1150	100	35	40Cr	43
		1220	100	35	40Cr	47
		1370	100	35	40Cr	51
		1520	100	35	40Cr	55
		1670	100	35	40Cr	58
	2.5T fork	920	100	45	40Cr	47
		1070	100	45	40Cr	50
		1150	100	45	40Cr	53
		1220	100	45	40Cr	57
		1370	100	45	40Cr	62
		1520	100	45	40Cr	67
		1820	100	45	40Cr	81
		920	122	40	40Cr	50
		1000	122	40	40Cr	51
		1070	122	40	40Cr	53
		1150	122	40	40Cr	61
		1220	122	40	40Cr	63
		1370	122	40	40Cr	70
		1520	122	40	40Cr	75
		1820	122	40	40Cr	85
	3T fork	920	122	45	40Cr	57
		1070	122	45	40Cr	63
		1220	122	45	40Cr	71
		1370	122	45	40Cr	76
		1520	122	45	40Cr	85
		1820	122	45	40Cr	96
CLASS III A		920	125	45	40Cr	66
		1000	125	45	40Cr	67
		1070	125	45	40Cr	68
		1150	125	45	40Cr	72
		1220	125	45	40Cr	74
		1370	125	45	40Cr	81
		1520	125	45	40Cr	90
		1670	125	45	40Cr	93
		1820	125	45	40Cr	105
		1970	125	45	40Cr	113
		2120	125	45	40Cr	120
		2270	125	45	40Cr	127
CLASS IV A	5T fork	1220	150	55	35CrMo	115
	5-6T fork	1220	150	60	35CrMo	128
		1370	150	60	35CrMo	135
		1520	150	60	35CrMo	142
		1670	150	60	35CrMo	149
		1820	150	70	35CrMo	180
		1970	150	70	35CrMo	189
		2120	150	70	35CrMo	218
		2270	150	70	35CrMo	229
		2420	150	80	35CrMo	240
	7t fork	1220	150	65	35CrMo	135
		1370	150	70	35CrMo	151
		1520	150	70	35CrMo	158
		1670	150	70	35CrMo	171
		1820	150	70	35CrMo	203
		1970	150	70	35CrMo	207
		2120	150	70	35CrMo	219
		2270	150	70	35CrMo	241
		2420	150	70	35CrMo	268
	8t fork	1220	170	70	35CrMo	157
		1370	170	70	35CrMo	188
		1520	170	70	35CrMo	197
		1670	170	70	35CrMo	213
		1820	170	80	35CrMo	244
		1970	170	80	35CrMo	254
		2120	170	80	35CrMo	272
		2270	170	80	35CrMo	286
		2420	170	80	35CrMo	323
SLEEVE	10t fork(shaft)	1220	175	80	35CrMo	189
		1370	175	85	35CrMo	213
		1520	175	85	35CrMo	224
		1670	175	85	35CrMo	245
		1820	175	85	35CrMo	255
		1970	175	85	35CrMo	266
		2120	175	85	35CrMo	293
		2270	175	85	35CrMo	308
		2440	175	85	35CrMo	337
